Cat6 S/FTP Shielded and Foiled Twisted pair Ethernet installation bulk cable 500Mhz

23AWG Solid bare copper, 305meter/1000ft, More color and Jacket material options bulk ethernet cable

FOB Ref Price

US$96-US$110

Model No.

FS17005

Color

Black,white,green,grey,blue,orange,yellow

Length

100m,305m,500M,1000M

Min. Order

100 Rolls

Lead Time

7-30 Days

Customization

Length, Color, Package

Share:

Share on facebook
Share on twitter
Share on linkedin
Share on email

Details about Cat6 S/FTP Shielded and Foiled Twisted pair Ethernet installation bulk cable 500Mhz

Farsince CAT6A S/FTP Shielded and Foiled Ethernet installation cable, is ideal for for high performance data communications for voice, data, video and security capabilities. This cable enables 10-Gigabit data transmission and allows for faster banderwith up to 500MHz Composed of four individually shielded pairs of 23 gauge solid bare copper conductors, with an overall Aluminum Magnesium Alloy braid shield, in order to repel electromagnetic interference (EMI) in electrically noisy environments, the CAT6A bulk Ethernet cable has an overall LSZH jacket and sequential foot or meter markings on the jacket so you always know how much it left.

Key Features

  • S/FTP
  • 23AWG 0.57mm Solid Oxygen-free Copper,
  • Foam-Skin insulation,
  • PVC/CMR/CMP/LSZH /PE Jacket options
  • More color options
  • Tested by Fluke and Network analyser
  • ROHS, REACH Compliance
  • CPR Eca, Dca Certificated

Standard Compliance

  • IEC/ISO 11801
  • ISO/IEC 61156-5
  • ANSI/TIA568C.2

Specifications

  • Conductor : 23AWG (1/0.57mm), Solid Bare Copper
  • Insulation: Foam skin PE
  • Shielding: Individual pair shielding by aluminum foil
  • Braiding: 16/5/0.12 AL-MG
  • Outer Diameter: 7.8 ± 0.2mm
  • Jacket Options: PVC, LSZH, CM, CMR(Riser), CMP(Plenum), PE (Outdoor),
  • Color: Grey/White/Blue/Black or Customized

Download:

  • Datasheet of Cat6 S/FTP Netwoking installation bulk cable

Order Information:

  • FS17005-C: PVC
  • FS17005-L: LSZH
  • FS17005-M: CM Rated
  • FS17005-R: CMR Riser
  • FS17005-P: CMP Plenum
  • FS17005-E: PE for outdoor

Request A Sample

We are glad to offer customer samples for evaluation before ordering, and most of them are FREE,  you just need to afford the shipping cost.

Please use the form below to request samples. Our sales representative will evaluate your requirements and contact you within 24 hours to confirm your request.
