Network extension cable male to female ethernet RJ45 UTP unshielded connector short cable

RJ45 unshielded male to female ethernet extension cable

FOB Ref Price

US$ 0.8 -US$ 5

Model No.

FS17501

Color

Black,white,green,grey,blue,orange,yellow

Length

0.3m,0.5m,1m,1.5m,1.8m,3m,5m,7.5m,10m,15m,20m,30m

Min. Order

200 Rolls

Lead Time

7-30 Days

Customization

Length, Color, Package

Share:

Share on facebook
Share on twitter
Share on linkedin
Share on email

Details about Network extension cable male to female ethernet RJ45 UTP unshielded connector short cable

Farsince RJ45 unshielded Male to Female Ethernet Extension Cable is perfect for extending the connection between all kinds of LAN network components through a panel. This allows the user to provide connectivity from a source that is contained within a secure location. It meets or exceeds Category 5E performance in compliance with the TIA/EIA-568-C.2 specifications. The connectors with gold-plated contacts, molded strain-relief boots, provide durability, and ensure a secure connection. Bare copper conductors enhance cable performance and comply with specifications for communications cables. Flexible and durable Cat5E cable with high bandwidth of up to 500 MHz guarantees high-speed data transfer for server applications, cloud computing, video surveillance, and online high-definition video streaming.

Key Features

  • High Quality U/UTP UnShielded Male to Female Extension Cable
  • Convenient way to extend the connection between all kinds of LAN network components through a panel
  • Meets or exceeds TIA/EIA -568-C.2 and ISO/IEC 11801 Specification
  • Provides outstanding transmission performance and low signal loss
  • Tested up to 600 MHz and support 10 Gigabit Ethernet
  • Available with different color of cable
  • Available with different length
  • ROHS, REACH Compliant

Specifications

  • Conductor : Bare copper
  • Wire Gauge: 26AWG or 24AWG
  • Insulation: HDPE
  • Insulation color: Blue/White,Blue; Orange/White, Orange; Green/White,Green; Brown/White,Brown
  • Shielding: none
  • Braiding: none
  • Jacket: PVC
  • Outer diameter: 6.2±0.2mm
  • Connector 1: RJ45 UTP male
  • Connector 1: RJ45 FTP female
  • Contact: Gold plated 3U
  • Testing: Fluke tester

Download:

  • Data sheet of RJ45 unshielded male to female ethernet extension cable

Order Information:

FS17501A**-xxx: Cat5e U/UTP male to female ethernet extension cable

FS17501B**-xxx: Cat6 U/UTP male to female ethernet extension cable

FS17501C**-xxx: Cat6A U/UTP male to female ethernet extension cable

  • **=color: GY=GREY, BK=BLACK, WT=WHITE, BU=BLUE, RD=RED, YL=YELLOW, OG=ORANGE, GN=GREEN
  • xxx=Length: 030=3.0M, 050=5.0M, 075=7.5M, 100=10M, 200=20M, 300=30M
  • For Example: FS17501BK-0003= Cat6 U/UTP male to female ethernet extension cable, 0.3M Length
