farsince LC/APC to LC/APC Singlemode OS2 9/125 Fiber Patch Cable, Simplex, 2.0mm Yellow Jacket, PVC/LSZH, Multiple Lengths
Low‑loss APC polish with ≥60 dB return loss. 100% tested with report—ideal for PON/FTTx, CATV and data center cross‑connects.
5.0
Model No.:
FS61A00
Brand:
Farsince / OEM
MOQ:
500
Trade Term:
EXW / FOB Ningbo
Lead time:
2–4 weeks
Customization:
Supported
Sample:
Available
Warranty:
1 Year
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Description
This OS2 singlemode patch cord uses LC/APC connectors with 8° angled polish to minimize back reflection, making it perfect for PON/FTTx and other reflection‑sensitive links. The 2.0 mm cable is lightweight and bend‑resistant, while zirconia ceramic ferrules and strain‑relief boots ensure long‑term reliability. Each assembly is interferometer‑checked and IL/RL tested, shipped with a test report. Available with PVC (OFNR) or LSZH jacket and multiple lengths.
Specifications
- Fiber: OS2 singlemode 9/125 μm (per ITU‑T G.652D/G.657.A1)
- Construction: Simplex
- Connectors: LC/APC ↔ LC/APC (green), zirconia ceramic
- Polish: APC 8°
- Performance: IL ≤0.3 dB (typ. 0.2 dB), RL ≥60 dB
- Wavelengths: 1310/1550 nm
- Jacket/Color: PVC (OFNR) or LSZH, yellow
- OD: 2.0 mm (0.9/3.0 mm optional by listing)
- Min bend radius: install ≥10×OD, dynamic ≥20×OD
- Operating temp: -20 to +70 °C
- Compliance: IEC 61754‑20 (LC), IEC 61300, GR‑326‑CORE ref., RoHS
