Description

This RG58C/U cable is a flexible, general‑use 50‑ohm coax designed for lab patching, radio interconnects and short antenna feeder runs. A stranded copper inner conductor with solid PE dielectric and a tinned‑copper braid maintain stable impedance and moderate loss, while the black PVC sheath provides easy handling and good flexibility. It terminates readily with common 50‑ohm connectors such as BNC, TNC, N‑type and SMA for use with test gear, transceivers, GPS receivers and RF modules.

Specifications

• Impedance: 50 Ω (RG58C/U)
• Conductor: Stranded tinned copper (typ. 19×0.18 mm)
• Dielectric: Solid polyethylene
• Shield: Tinned copper braid (high coverage)
• Jacket: Black PVC
• Outer Diameter: ~4.9–5.0 mm (0.195 in)
• Velocity Factor: ~0.66
• Capacitance: ~100–101 pF/m
• Attenuation (approx., per 100 m): 20 dB @100 MHz; 44 dB @400 MHz; 70 dB @900 MHz
• Temperature Range: about −20 to +80 °C
• Terminations: BNC/TNC/N/SMA 50‑ohm connectors
• Applications: RF patch leads, radios, test instruments, short antenna feeders
• Compliance: RoHS (vendor dependent)
• Packaging: Reels or cut lengths
