Description

The Farsince 1U 24‑port Cat6 unshielded patch panel uses industry‑standard 110 IDC punch‑down blocks and supports 22–26 AWG solid or stranded copper conductors for fast, reliable terminations. Engineered to meet ANSI/TIA‑568.2‑D Category 6 and ISO/IEC 11801 Class E, it delivers stable Gigabit performance at 250 MHz and supports 2.5/5GBASE‑T on qualified channels. A rigid SPCC steel chassis with rear cable management bar, tie‑down points, sequential port numbering, and writable label windows keeps racks neat and serviceable. Fully IEEE 802.3af/at/bt PoE compatible for enterprise, surveillance, and low‑voltage deployments.

SpecifCa

• Category/Performance: Cat6 (Class E), 250 MHz; meets ANSI/TIA‑568.2‑D and ISO/IEC 11801
• Ports: 24 × RJ45 (8P8C), front‑numbered 1–24 with label windows/cards
• Termination: 110‑type IDC punch‑down, supports T568A/B wiring; use standard impact tool
• Cable Compatibility: 22–26 AWG solid or stranded; insulation OD approx. 0.4–0.6 mm; typical cable OD ≤ 7.5–8.0 mm (varies by cable)
• Electrical/Ethernet: 10/100/1000BASE‑T; 2.5/5GBASE‑T supported on qualified channels
• PoE Support: IEEE 802.3af/at/bt compatible (up to 90 W; actual depends on cable type, bundle size, and temperature rise)
• Materials: SPCC steel chassis (black powder‑coat); flame‑retardant PC/ABS modules (UL 94V‑0); contacts with nickel underplate and gold plating (typ. ≥30 μin); IDC terminals tinned phosphor bronze
• Mounting: 1U, 19" rack (EIA/ECA‑310); includes rack screws/cage nuts
• Compliance: RoHS/REACH; interface per IEC 60603‑7
• Options: 12‑port/48‑port and Cat5e/Cat6A variants; rear management bar or rings
