Description

The Farsince 1U 24‑port Cat6 shielded patch panel features a metal‑shielded housing and grounding provision to reduce EMI and alien crosstalk for stable Gigabit links. Dual‑standard Krone/110 IDC blocks support T568A/B wiring and accept 22–26 AWG solid or stranded copper conductors for fast, flexible terminations. A rear cable management bar, tie‑down points, sequential port numbering, and writable labels keep racks neat and serviceable. Qualified channels can support 2.5/5GBASE‑T. Fully IEEE 802.3af/at/bt PoE compatible for enterprise, building, and surveillance deployments.

Specifications

• Category/Performance: Cat6 (Class E), 250 MHz; meets ANSI/TIA‑568.2‑D and ISO/IEC 11801
• Ports: 24 × RJ45 (8P8C), front‑numbered 1–24 with label windows/cards
• Shielding/Grounding: Metal‑shielded jack housings with shield tabs; rear grounding stud/strap provision (hardware included by model)
• Termination: Dual‑standard IDC (Krone & 110), T568A/B; color‑coded wiring; use standard impact tool
• Cable Compatibility: 22–26 AWG solid/stranded; insulation OD approx. 0.4–0.6 mm; typical cable OD 5.0–8.5 mm (varies by cable)
• Ethernet & PoE: 10/100/1000BASE‑T; 2.5/5GBASE‑T on qualified links; IEEE 802.3af/at/bt compatible (up to 90 W, subject to bundle size and temperature rise)
• Materials: SPCC steel chassis (black powder‑coat); nickel‑plated shield shell; contacts with nickel underplate and gold plating (typ. ≥30 μin); tinned phosphor‑bronze IDC
• Mounting: 1U, 19" rack (EIA/ECA‑310); includes rack screws/cage nuts and rear management bar (as supplied)
• Compliance: RoHS/REACH; interface per IEC 60603‑7; UL/ETL listings available by variant
• Dimensions/Weight: Standard 1U width 482.6 mm; depth/weight depend on configuration
