Description

This is a straight M8 A‑Code 4‑pin female to open wires cable. The M8 A‑Code female mates to standard 4‑pin A‑code male ports; the opposite end is delivered as four open conductors prepared for stripped, tinned or ferruled termination to terminal blocks, harnesses or device inputs. It is ideal for panel wiring, field terminations and compact sensor/actuator installations.

Constructed with 4 × 0.25 mm² stranded copper conductors and HDPE insulation, the cable provides a compact 4.20 ± 0.30 mm O.D. and a minimum bend radius of 7.5 × D for reliable routing (≈31 mm). Supplied with a black outer jacket in PVC or PUR, the cable maintains IP67 when mated. Unshielded by default; shielding options available for EMI‑sensitive environments. Standard 4‑pin pin‑out conventions apply.

Specifications

• Product Type: M8 A-Code 4-Pin Female to Open Wires Cable (straight)
• Connector: M8 A-Code 4-Pin Female, nickel‑plated shell
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 4×0.25 mm² (14×0.15 mm) stranded copper
• Insulation: HDPE
• Jacket: PVC/PUR, Black
• Cable O.D.: 4.20 ± 0.3 mm
• Min bend radius: 7.5 × D (≈31 mm)

• Lengths: 1 m, 3 m, 5 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: Sensors, actuators, digital I/O, PLC I/O — Not recommended for high‑speed Ethernet
• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
