Description

This is a straight M8 A‑Code 3‑pin male to open wires cable. The M8 A‑Code male mates to standard 3‑pin A‑code female ports; the opposite end is delivered as three open conductors prepared for stripped, tinned or ferruled termination to terminal blocks, harnesses or device inputs. It targets sensor and actuator connections, discrete I/O, short inline extensions and cabinet routing where a straight connector simplifies alignment with mating ports.

Constructed with 3 × 0.25 mm² stranded copper conductors and HDPE insulation, the cable provides a compact 4.00 ± 0.30 mm O.D. and a minimum bend radius of 7.5 × D for reliable field routing (≈30 mm). The cable features a black outer jacket in either cost‑effective PVC for fixed runs or oil‑ and flex‑resistant PUR for dynamic applications, both maintaining an IP67 seal when mated. Unshielded by default with a braided/tinned copper shield option; standard 3‑pin pin‑out conventions apply.

Specifications

• Product Type: M8 A-Code 3-Pin Male to Open Wires Cable (straight)
• Connector: M8 A-Code 3-Pin Male, nickel‑plated shell
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 3×0.25 mm² (14×0.15 mm) stranded copper
• Insulation: HDPE
• Jacket: PVC/PUR, Black
• Cable O.D.: 4.00 ± 0.3 mm
• Min bend radius: 7.5 × D (≈30 mm)

• Lengths: 1 m, 3 m, 5 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: Sensors, actuators, digital I/O, PLC I/O — Not recommended for high‑speed Ethernet
• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
