Description

This M12 A‑Code 4‑pin cable pairs a molded straight M12 A‑code male connector with four open conductors to simplify sensor, actuator and small actuator cabling on the machine floor. Conductors are 4×0.34 mm² stranded bare copper with HDPE insulation. The overall cable diameter is 4.5 ± 0.3 mm and the black PUR outer jacket provides abrasion, oil and flex resistance while maintaining IP67 protection when mated.

Engineered for reliable field terminations, the cable supports fixed and moderate-flex installations across −40 °C to +80 °C. Minimum bending radius is 7.5×D. Farsince supplies standard and bespoke lengths, alternative end treatments, custom marking and factory continuity checks to align assemblies with PLC I/O, encoder and distributed I/O wiring practices.

Specifications

• Product Type: M12 A-Code 4-Pin Male to Open Wires Cable (straight)
• Connector: M12 A-Code 4-Pin Male, nickel‑plated shell
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 4×0.34 mm² (19×0.15 mm) stranded copper
• Insulation: HDPE
• Jacket: PUR, Black
• Cable O.D.: 4.5 ± 0.3 mm
• Min bend radius: 7.5 × D (≈34 mm)

• Lengths: 3 m, 5 m, 10 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: IO‑Link, digital I/O, sensors, actuators, PLC I/O — Not recommended for high‑speed Ethernet

• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
