Description

This is an M12 A‑Code 4‑pin right‑angle (elbow) male to open wires cable with a PVC/PUR outer jacket. The right‑angle M12 male mates to standard A‑code female ports; the opposite end is delivered as open conductors for direct termination to terminal blocks, wire harnesses or device inputs. It is intended for IO‑Link, digital I/O, sensor and actuator wiring in factory automation, machine tools, conveyors and distributed I/O cabinets where space for straight connectors is limited.

The cable features a black outer jacket in either ​cost-effective PVC for fixed runs​ or ​oil- and flex-resistant PUR for dynamic applications, both maintaining an IP67 seal when mated. Unshielded by default (shielded option available), it follows standard 4‑pin pin‑out conventions and ships in 3 m / 5 m / 10 m lengths with custom lengths on request.

Specifications

• Product Type: M12 A‑Code 4‑Pin Male Right‑Angle (Elbow) to Open Wires Cable
• Connector: M12 A-Code 4-Pin Male, right‑angle, nickel‑plated shell
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 4×0.34 mm² (19×0.15 mm) stranded copper
• Insulation: HDPE
• Jacket: PVC/PUR, Black
• Cable O.D.: 4.5 ± 0.3 mm
• Min bend radius: 7.5 × D (≈34 mm)

• Lengths: 3 m, 5 m, 10 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: IO‑Link, digital I/O, sensors, actuators, PLC I/O — Not recommended for high‑speed Ethernet
• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
