Description

This cable pairs an M12 A‑Code 4‑pin female straight connector with open conductors prepared for stripped, tinned or ferruled termination. The M12 female mates to standard A‑code male ports; the open end allows direct connection to terminal blocks, device inputs or harness splices. It is intended for IO‑Link, digital I/O, sensor and actuator wiring in machine cabinets, conveyor systems and distributed I/O installations.

The cable features a black outer jacket in either ​cost-effective PVC for fixed runs​ or ​oil- and flex-resistant PUR for dynamic applications, both maintaining an IP67 seal when mated. Unshielded by default (shielded option available), the product follows common 4‑pin pin‑out conventions and  and ships in 3 m / 5 m / 10 m lengths with custom lengths on request.

Specifications

• Product Type: M12 A‑Code 4‑Pin Female to Open Wires Cable (straight)
• Connector: M12 A-Code 4-Pin Female, nickel‑plated shell
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 4×0.34 mm² (19×0.15 mm) stranded copper
• Insulation: HDPE
• Jacket: PVC/PUR, Black
• Cable O.D.: 4.5 ± 0.3 mm
• Min bend radius: 7.5 × D (≈34 mm)

• Lengths: 3 m, 5 m, 10 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: IO‑Link, digital I/O, sensors, actuators, PLC I/O — Not recommended for high‑speed Ethernet
• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
