Description

This cable features an M12 A‑Code 4‑pin female right‑angle connector mated to open conductors prepared for stripped, tinned or ferruled terminations. The elbow connector orientation enables reliable mating in tight spaces, on sensor brackets or panel edges where a straight connector interferes with adjacent components.

Built with 4 × 0.34 mm² stranded copper conductors and HDPE insulation. The cable features a black outer jacket in either ​cost-effective PVC for fixed runs​ or ​oil- and flex-resistant PUR for dynamic applications, both maintaining an IP67 seal when mated. Unshielded by default (shielded option available). It is suitable for IO‑Link, discrete I/O, sensor and actuator wiring on machines, robots and modular I/O racks.

Specifications

• Product Type: M12 A‑Code 4‑Pin Female Right‑Angle (Elbow) to Open Wires Cable
• Connector: M12 A-Code 4-Pin Female, right‑angle, nickel‑plated shell
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 4×0.34 mm² (19×0.15 mm) stranded copper
• Insulation: HDPE
• Jacket: PVC/PUR, Black
• Cable O.D.: 4.5 ± 0.3 mm
• Min bend radius: 7.5 × D (≈34 mm)

• Lengths: 3 m, 5 m, 10 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: IO‑Link, digital I/O, sensors, actuators, PLC I/O — Not recommended for high‑speed Ethernet
• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
