Description

This is a straight 7/8" A‑Code 4‑pin male to open wires cable. The 7/8" A‑Code threaded male mates to standard 7/8" female ports; the opposite end is delivered as four open conductors prepared for field termination (stripped/tinned/ferruled). Designed for sensors, actuators, valves and industrial I/O where a secure threaded connection and field wiring are required.

Constructed with 4 × 1.5 mm² (42 × 0.10 mm) stranded copper conductors with PP insulation, the assembly has a nominal cable O.D. of 7.80 ± 0.40 mm. Outer jacket is PVC (standard) or PUR (optional) for improved oil/abrasion resistance and flex life. Mated and tightened (7/8" UNF thread, recommended torque 1.5 Nm) the connector achieves IP67. Default unshielded; shielding options available for EMI‑sensitive applications.

Specifications

• Product Type: 7/8" A‑Code 4‑Pin Male to Open Wires Cable (straight)
• Connector: 7/8" A‑Code 4‑Pin Male, nickel‑plated shell, self‑locking thread
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 4 × 1.5 mm² (42 × 0.10 mm) stranded copper
• Insulation: PP
• Jacket: PVC/PUR, Grey (other colors on request)
• Cable O.D.: 7.80 ± 0.40 mm
• Min bend radius: Static ≥ 6 × OD (≈ 46.8 mm); Recommended dynamic/flex ≥ 7.5 × OD (≈ 58.5 mm)
• Lengths: 3 m, 5 m, 10 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: Industrial sensors, actuators, valves, power and I/O points — Not recommended for high‑speed Ethernet
• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
