Description

This is a straight 7/8" A‑Code 4‑pin female to open wires cable. The 7/8" female mates to standard A‑Code male ports; the free end provides four open conductors for termination at PLCs, terminal blocks or devices. Ideal for panel entry and fixed installations requiring a sealed threaded female connector.

Manufactured with 4 × 1.5 mm² stranded copper conductors and PP insulation; cable O.D. 7.80 ± 0.40 mm. Jacket default PVC; PUR option for dynamic/oily environments. Achieves IP67 when mated and tightened (recommended torque 1.5 Nm). Unshielded by default; shielding available for EMI‑sensitive applications.

Specifications

• Product Type: 7/8" A‑Code 4‑Pin Female to Open Wires Cable (straight)
• Connector: 7/8" A‑Code 4‑Pin Female, nickel‑plated shell, self‑locking thread
• Termination: Open wires (options: stripped; tinned; ferruled)
• Conductor: 4 × 1.5 mm² (42 × 0.10 mm) stranded copper
• Insulation: PP
• Jacket: PVC/PUR, Grey (other colors on request)
• Cable O.D.: 7.80 ± 0.40 mm
• Min bend radius: Static ≥ 6 × OD (≈ 46.8 mm); Recommended dynamic/flex ≥ 7.5 × OD (≈ 58.5 mm)
• Lengths: 3 m, 5 m, 10 m (custom lengths available on request)
• IP Rating: IP67 when mated
• Operating Temp: −40 °C to +80 °C
• Installation Temp: −5 °C to +60 °C

• Compatibility: Industrial sensors, actuators, valves, power and I/O points — Not recommended for high‑speed Ethernet
• Compliance: RoHS, REACH
• Customization: Pin-out, length, shielding, overmolding, marking available
• Service Support: Cable assembly, 100% continuity testing, batch traceability, ODM support
