Description

This product is a CY‑type LSZH screened control cable for industrial automation and building systems requiring EMI control and low‑smoke performance. It employs flexible class‑5 copper conductors insulated with halogen‑free compound and an overall tinned‑copper wire braid beneath an LSZH outer sheath. The braided screen offers uniform coverage to protect analog/digital control signals and low‑voltage power in cabinets, HVAC plants, conveyors and process lines. Rated 300/500 V, it suits PLC I/O, drives, interlocks, sensors and measurement loops on fixed or intermittently flexed runs in dry or damp indoor areas.

Specifications

• Product Type: CY LSZH braided‑screen flexible control cable
• Voltage Rating: 300/500 V
• Conductor: Class 5 flexible bare copper (tinned optional)
• Core Count: Multiple options; green/yellow PE core on request
• Conductor Size: Typical options 0.5–2.5 mm²
• Insulation: Halogen‑free compound, numbered cores
• Shielding: Overall tinned copper wire braid (TCWB)
• Sheath: LSZH outer jacket, grey or black
• Application: PLC I/O, drives, sensors, HVAC and building automation
• Installation: Fixed or occasional flexing; not for continuous drag‑chain use
• Environment: Indoor dry or damp locations
• Fire & Smoke: IEC 60332‑1‑2; IEC 60754‑1/2; EN 61034
• Compliance: RoHS, REACH
• Cable Length: Supplied on reels or custom cuts
• Customization: Core count/size, jacket color/print, armouring, screened pairs, harnesses
