Description

The Farsince OS2 MTP/MPO to LC Breakout Cable is designed for high-density fiber cabling and singlemode breakout applications in data centers. It is available in 8-fiber and 12-fiber versions, with an MTP/MPO APC connector on one end and LC/UPC duplex legs on the other.

Supplied with Type B mapping by default, this cable uses OS2 9/125 μm singlemode fiber, a 3.0 mm trunk, and 2.0 mm legs for organized installation in dense patching environments. PVC and LSZH jacket options are available for different project requirements.

Farsince also supports customization for fiber count, polarity, leg length, and jacket type. Each assembly is factory terminated and tested to help ensure consistent quality and reliable field performance.

Specifications

• Fiber Type: OS2 singlemode, 9/125 μm, ITU-T G.652D / G.657.A1
• Fiber Count: 8F or 12F
• Breakout Configuration: 8F → 4 × LC duplex; 12F → 6 × LC duplex
• Connector A: MTP/MPO APC 8°, default female; male optional
• Connector B: LC/UPC duplex
• Polarity / Mapping: Type B breakout by default; Type A/C customizable
• Cable Structure: 3.0 mm trunk + 2.0 mm legs
• Default Fan-out Length: 0.5 m
• Strength Member: Aramid yarn
• Jacket Options: PVC (OFNR) or LSZH
• Cable Color: Yellow
• MTP/MPO Elite Performance: IL ≤0.35 dB @12F, ≤0.25 dB @8F, RL ≥60 dB
• MTP/MPO Standard Performance: IL ≤0.75 dB @12F, RL ≥60 dB
• LC End Performance: IL ≤0.3 dB, typical 0.2 dB, RL ≥50 dB
• Bend Radius: ≥10D static, ≥20D dynamic
• Operating Temperature: -20°C to +70°C
• Testing: 100% IL/RL and 3D end-face inspection, with test report and polarity map
• Compliance: IEC 61754-7-3, IEC 61754-20, IEC 61300, RoHS, REACH
