Farsince LC UPC to LC UPC Multimode OM5 50/125 Duplex Fiber Patch Cable, 2.0mm Lime Green, Tight‑Buffered, OFNR (Riser)
Bend‑insensitive OM5 (7.5 mm min bend radius) with low‑loss zirconia LC duplex. Zipcord tight‑buffered design, color‑coded jacket, OFNR flame rating. 100% IL/RL and end‑face tested.
5.0
Model No.:
FS61D00
Brand:
Farsince / OEM
MOQ:
500
Trade Term:
Farsince / OEM
Lead time:
2–4 weeks
Customization:
Supported
Sample:
Available
Warranty:
1 Year
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Description
Built with bend‑insensitive OM5 fiber optimized for the 850–953 nm band, this cable enables SWDM to run 40/100G over just two fibers. LC/UPC duplex connectors with zirconia ferrules ensure low insertion loss and reliable mating. The 2.0 mm zipcord, tight‑buffered construction is robust and easy to route, while the lime‑green jacket simplifies identification. Each assembly is interferometer‑checked and IL/RL tested with a report.
Specifications
- Fiber: OM5 MM 50/125 μm (BIF; TIA‑492AAAE, IEC 60793‑2‑10 A1a.4)
- Fiber count: 2 (Duplex)
- Connectors: LC/UPC Duplex to LC/UPC Duplex
- Polarity: A(Tx) to B(Rx)
- Jacket/Structure: 2.0 mm tight‑buffered zipcord; color: lime green
- Flame rating: OFNR (Riser)
- Optical performance: IL ≤0.3 dB (typ. 0.2 dB); RL ≥30 dB
- Attenuation: 3.5 dB/km @850 nm; 1.5 dB/km @1300 nm
- Bend radius: 7.5 mm min (optical fiber); cable 20D/10D (dynamic/static)
- Tensile strength: 90/150 N (long/short term)
- Mating durability: ≥1000 cycles
- Operating/Storage temp: −10 to +70 °C / −20 to +70 °C
- Typical reach: 10GBASE‑SR up to 550 m; 40/100G SWDM4 up to 440 m/150 m (system‑dependent)
