Description

This farsince Cat6A shielded keystone jack uses a metal housing with a grounding spring to suppress EMI/alien crosstalk. The tool‑less latch‑down design completes T568A/B wiring quickly and reliably. Gold‑plated phosphor‑bronze contacts and flame‑retardant materials ensure long‑term durability. The standard keystone footprint fits common wall plates and 19‑inch patch panels and supports 500 MHz/10 Gbps plus IEEE 802.3af/at/bt (4‑pair PoE).

Specifications

• Category/Performance: Cat6A (Class EA), 500 MHz, up to 10 Gbps
• Shielding: Full‑metal shell with 360° grounding
• Termination: Tool‑less; T568A/B selectable; typical 180° cable exit
• Conductor Range: 22–26 AWG solid/stranded; insulation OD ~0.9–1.6 mm
• Cable Jacket OD Supported: ~6.0–8.0 mm (typical)
• Contacts: Phosphor‑bronze, thick gold on mating area
• Housing: PC/ABS UL94V‑0 with metal shield
• Footprint: Standard keystone size for wall plates and 19" patch panels
• PoE: IEEE 802.3af/at/bt compatible
• Compliance: ANSI/TIA‑568.2‑D, ISO/IEC 11801, IEC 60603‑7‑51; RoHS/REACH
